All Weather Sound Panels

All Weather Sound Panels®

The Panels

Our patented All Weather Sound Panels® give you high sound transmission loss coupled with high sound absorption, all in a weather resistant package. We engineered these incredibly durable and easily maintained panels specifically to resist the most rigorous industrial uses and outdoor environments.

The panels present an amazing profile of just under 2.5”. We produce them in four standard rectangular sizes, but can custom make them in any size, provided the shape is square or rectangular.

All Weather Sound Panels

All Weather Sound Panels®

Hurricane & Industrial

Panel Versions (All less than 2.5″ thick)

We have 4 panel versions available: (Custom Sizes Available)

  • Aerogel All Weather Sound Panels – Static Wind Load tested > 200 MPH
  • Tornado All Weather Sound Panels – Static Wind Load tested > 360 MPH
  • Hurricane All Weather Sound Panels – Static Wind Load tested > 270 MPH
  • Industrial All Weather Sound Panels – Static Wind Load tested > 200 MPH

Panel Specs

The panels have an acoustical performance of STC 30 up to STC 37 and NRC 1.0. This yields a sound transmission loss of 37dB depending on the panel model with virtually no reflections off the face of the panel.

All of the panels have similar specifications:

  • A UL 723 classification (ASTM E84-07, Test for surface burning characteristics of building materials)
  • A strain hardened corrosion resistant perforated aluminum fascia
  • A strain hardened corrosion resistant solid back for higher fire ratings.
  • A welded 2.423” aluminum extruded frame assembly.
  • All mounting eyelets are welded crush proof tubes.
All Weather Sound Panels

AWSP Carriage Systems (Patented)

An All Weather Sound Panel can be attached to a mobility carriage, which allows a single person to move the panel easily. Multiple panels outfitted with the carriage system can be attached together, allowing a single person to move the entire assembly, as seen in these images.

Note: The carriage is for portability only, where wind and poor floor surface are not a factor.  They are not for structural or fixed installation.

AWSP Carriage Systems (Patented)

An All Weather Sound Panel can be attached to a mobility carriage, which allows a single person to move the panel easily. Multiple panels outfitted with the carriage system can be attached together, allowing a single person to move the entire assembly, as seen in these images.

Note: The carriage is for portability only, where wind and poor floor surface are not a factor.  They are not for structural or fixed installation.

AWSP Carriage Systems
AWSP Carriage Systems

Custom AWSP Mobile Enclosure

Custom mobility carriages were designed to accommodate two larger custom panels per carriage.  This enabled the creation of a massive sealed enclosure that is fully mobile and can be separated for easy access to the interior of the enclosure.

Note: The carriage is for portability only, where wind and poor floor surface are not a factor.  They are not for structural or fixed installation.

Custom AWSP Mobile Enclosure

Custom mobility carriages were designed to accommodate two larger custom panels per carriage.  This enabled the creation of a massive sealed enclosure that is fully mobile and can be separated for easy access to the interior of the enclosure.

Note: The carriage is for portability only, where wind and poor floor surface are not a factor.  They are not for structural or fixed installation.

All Weather Sound Panels
All Weather Sound Panels

Custom AWSP Exhaust Chimney Enclosure

Custom AWSP Exhaust Chimney Enclosure

All Weather Sound Panels

All Weather Sound Panels®

Video Gallery

Powder Coated Louver Panels

Hammered Copper Look

Custom Finish Samples

Large Noise Enclosure

All Weather Sound Panels

All Weather Sound Panels®

Static Wind Load Test

The sample was tested in accordance with Florida Building Code and ASTM Test Standards, specifically it was tested in accordance with FBC TAS 202, Miami-Dade County Test protocol PA202, and ASTM E 330 with no deviations.  It was tested to a design pressure of 60 PSF without any failure.

See the Video!

All Weather Sound Panels®

Static Wind Load Test

The sample was tested in accordance with Florida Building Code and ASTM Test Standards, specifically it was tested in accordance with FBC TAS 202, Miami-Dade County Test protocol PA202, and ASTM E 330 with no deviations.  It was tested to a design pressure of 60 PSF without any failure.

See the Video!

All Weather Sound Panels

Uses for All Weather Sound Panels®

  • Highway Road Noise
  • Stadiums
  • Railroad Yards
  • Churches
  • Noisy Air Conditioners
  • Kitchens
  • Gymnasiums
  • Kennels
  • Marine Vessels
  • Engine Noise
  • Auditoriums
  • Transportation Barriers
  • Industrial Machinery Areas
  • Engine Test Cells
  • Power Plants
  • Shooting Ranges
  • Subways
  • Zoos
  • Mining Operations
  • Recording Studios
  • Airports
  • Commercial Vehicles
  • Community Noise Control
  • Schools
  • Correctional Facilities
  • Hospitals
  • Childcare Centers
  • Racetracks
  • Swimming Pool Areas
  • Restaurants
  • Construction Sites
  • Night Clubs
All Weather Sound Panels
All Weather Sound Panels
All Weather Sound Panels

AWSP with Foliage Covering

All Weather Sound Panels®

90 Degree Corner Round & T-Bar Connectors

This image shows the custom 4-1/8″ x 4-1/8″ x 1/4″ extruded aluminum, 90 degree corner-round connector, incorporating the 6063-T6 alloy mill finish. This connector is used to secure All Weather Sound Panels when a right angle is required for assembly.

All Weather Sound Panels
All Weather Sound Panels

All Weather Sound Panels®

Noise Solution Applications

Customer Project Examples

Customer Project Examples
